SPECIFICATIONS
Dimensions
Power
- Power Source - 56.7 V
- Motor Type - 56 Volt AC
- Horsepower - (KW) 8.7 kW Peak
- Electrical System - 56 Volts
- Batteries - Single, 56 V Li-Ion (Standard
- Configuration)
- Key or Pedal Start - Pedal Start
- Rear Axle Ration - 17:1 (Forward)
- Gears Gear Selection - Dash Mounted Forward-Neutral-Reverse
- Drivetrain - Motor Shaft Direct Drive
- Transaxle - Differential with Helical
- Speed Controller - 235 Amp AC
- Battery Charger - 56VDC, 120/230 VAC, UL/CSA, CE
Performance
- Seating Capacity - 4-Passengers
- Dry Weight - 416kg without Batteries
- Curb Weight - 437 kg
- Vehicle Load Capacity - 360 kg
- Outside Clearance Circle 0 7m
- Speed (Level Ground) - Up to 30.6 kph ± 0.8 kph
Steering & Suspension
- Steering - Self-Compensating Rack and Pinion
- Suspension - Leaf Springs with Hydraulic Shock Absorbers
- Service Brake - Rear Wheel Mechanical Self-Adjusting Drum
- Parking Brake - Self-Compensating, Single Point Engagement
Body & Chassis
- Frame - Welded Steel with E-Coat & DuraShieldTM Powder Coat
- Body & Finish - Injection Molded TPO
