- Overall Length - 279.4cm
- Overall Width - 125cm
- Overall Height - 119.4 cm (no Canopy 176.5cm (w/ Struts & Roof)
- Wheel Base - 166.4cm
- Wheel Track 94cm Front / 96.5cm Rear
- Ground Clearance - 10.9cm
- Cargo Box Capacity - (0.24cu m)
- Cargo Box Dimensions- (72.4x113x30.5cm)
- Cargo Box Material - Roto-Molded Polyethylene
SPECIFICATIONS
2
100AH Samsung Lithium battery
4
Manul tipping deck
3
Standard roof
1
Bush Guard
Dimensions
Power
- Power Train - 56.7V Li-Ion battery
- Valve Train - N/A
- Horsepower (kw) - 11.7 hp (8.7 kW) Peak
- Electrical System - 48V Primary, 12V auxiliary
- Battery (Qty/Type) - 2.2 Elite - Single pack
- Key or Pedal Start - Pedal
- Drive Train - Motor shaft direct Drive
- Transaxle - Differential w/ helical gears
- Gear Selection - Dash mount Forward
- Neutral-Reverse / Key switch
- Rear Axle Ration - 19.99:1
Performance
- Seating Capacity - 2-Person (Bench)
- Weight w/o Batteries - 342kg
- Curb Weight - 363kg
- Vehicle Load Capacity - 362.9kg
- Bed Load Capacity - 191.4kg
- Towing Capacity - 408.2kg
- Outside Clearance Circle - 5.8m
- Speed - 26.5 kph ± 0.8 kph
Steering & Suspension
- Steering - Self-Compensating rack and pinion
- Suspension - Leaf springs w/ hydraulic shock absorbers
- Service Brake - Rear wheel Mechanical Self-Adjusting drum
- Parking Brake - Self-compensating, single-point engagement
- Tires (Front & Rear) - 8 x 8.5 -8 (6 Ply Tires)
Body & Chassis
- Frame - Welded steel with E-Coat & DuraShield Power Coat
- Body - Injection moulded TPO
- Standard colour - Forest green - can be repainted to a colour of your choosing
